Tests of the power oil transformer ТМ-1000/11-Т1

One of the requirements required for the supply of this transformer was the qualification tests (TYPE TEST) of the power oil transformer TM-1000/11-T1 11/0.4 Д/Ун-11, which were carried out at the testing facilities of PJSC “VIT”. (link to the site PAT "VIT")

Tests were conducted in the period from 10/05/2018. till 11.10.2018

The tests were successful.
The test results are documented by protocols.

Tests of the power oil transformer ТМ-1000/11-Т1

Transformer ТМ-1000/11-Т1





Tests of the power oil transformer ТМ-1000/11-Т1

Transformer plate





Tests of the power oil transformer ТМ-1000/11-Т1

When tested at PAO "VIT"

Tests of the power oil transformer ТМ-1000/11-Т1

When tested at PAO "VIT"
