6-10 kV One-phase two-windings power transformers ОМП, ОМ, ОМС

6-10 kV One-phase two-windings power transformers ОМП, ОМ, ОМС

  One-phase transformers of OM series are designed to convert electricity in power grids, for electric railways power supply, for feeding of complex cathodic protection devices (for protection of pipelines, overpasses) and other single-phase 220V power consumers.
Download questionnaire OM.doc [40 Kb] (downloads: 15)

  Rated power, kVA
Naming 1,25 2,5 4 6,3 10
ОМП
ОМ




  The transformers are made in 6-10 kV voltage class and has power line 1,25; 2,5; 4; 6 and 10 kVA, may be used for feeding of any single-phase consumers.
Climatic performance У, УХЛ with accommodation category 1, for non-explosive ambience and for acceptable dust concentrations, which allows keeping the transformers parameters in the declared range.
  The voltage adjustment is performed on HV side by steps ±2х2,5% of rated voltage, while all the windings are disconnected of the grid (reconnection without excitation).
  The transformers are equipped by oil indicators to check oil level in the tank.
Upon customers request, penetrative fuse can be mounted on LV side.
The transformers are performed as per TУ У 27.1-13608660-049-2014.

Th etransformers complies to ГОСТ 11677.
